All-in-One POS Terminal
Grace G5
POS Terminal
15.6″ PCAP Touchscreen — Slim Bezel, IP54, Multi-Display
The Partner Tech Grace G5 is a modern, high-performance all-in-one POS terminal designed for retail, hospitality, and food & beverage environments. A vibrant 15.6″ PCAP touchscreen, Intel Celeron Elkhart Lake processor, fast M.2 SSD storage, and a fanless design deliver speed, reliability, and flexibility — with IP54 spill and dust resistance and support for up to two independent displays.
15.6″ PCAP touchscreen
Slim-bezel, 220-nit display with smooth multi-touch response for fast, accurate staff interactions
Intel Elkhart Lake CPU
Intel Celeron J6412 with up to 16GB DDR4 RAM and up to 512GB M.2 PCIe SSD storage
Dual independent displays
Drive a customer-facing screen or signage display via HDMI alongside the main touchscreen
IP54 certified
Spill and dust resistant — built to handle the demands of hospitality and food service environments
Fanless design
Silent, maintenance-free operation — no dust build-up, no noise at the counter
Foldable base design
Compact footprint for tight counters; folds flat for easier transport and reduced shipping costs
Processor & memory options
Processor
Celeron J6412
Intel Elkhart Lake
Quad Core
RAM
4 – 16GB
DDR4
4GB / 8GB / 16GB
Storage
128GB – 512GB
M.2 PCIe SSD
128G / 256G / 512G
Display & compute
| Display size | 15.6″ |
| Resolution | 1366 × 768 (16:9) |
| Brightness | 220 nits (typical) |
| Touch type | PCAP multi-touch |
| Display outputs | 2 independent (main + HDMI) |
| Speaker | 3W built-in |
Physical & environment
| Dimensions (W×H×D) | 392 × 291 × 224mm |
| Weight | 5kg |
| IP rating | IP54 (spill & dust resistant) |
| Operating temp | 0°C–40°C, 15%–80% RH |
| Storage temp | -20°C–60°C |
| Power supply | AC 100–240V / DC 12V, 65W |
| OS support | Windows 10, Windows 11, Ubuntu 22.04 |
I/O ports & connectivity
USB
2× USB 3.2
4× USB 2.0
Serial & network
3× COM RS232 (RJ45)
1× LAN (GbE, RJ45)
Display & audio
1× HDMI
1× Audio line-out
1× DC out 12V
POS & wireless
1× Cash drawer RJ11 (2 drawers, 24V/12V)
Wi-Fi 6E + BT 5.2 (optional)
Ideal for
Retail & POS Cafés & coffee shops Restaurants Takeaway & quick service Hospitality Healthcare & services
IP54 certification means the Grace G5 is rated against spills and dust — making it one of the few slim all-in-one terminals built to withstand the realities of busy food service and hospitality counters.
