Hands-Free Presentation Scanner
Voyager 7680G
2D Barcode Scanner
Honeywell Genesis XP — 1D, 2D, PDF & Mobile Screen Ready
The Honeywell Voyager 7680G is a high-performance hands-free presentation scanner built for fast, accurate barcode capture in demanding retail and POS environments. Honeywell's Genesis XP imaging technology reads 1D, 2D, PDF, and DotCode barcodes — including damaged, poorly printed, and mobile screen codes — with a 360° LED feedback ring and automatic object detection for intuitive, effortless operation.
1D, 2D & PDF decode
Reads all standard barcode types including QR, Data Matrix, DotCode, and Digimarc — even from mobile screens
Genesis XP technology
Faster scan speeds and a wider scanning area reduce wait times and improve checkout efficiency
Auto object detection
Scanner activates only when a barcode is presented — reducing distractions and unnecessary scanning
360° LED feedback ring
Soft white illumination and clear visual confirmation make scanning intuitive for staff and customers alike
IP52 & drop tested
Rated IP52 with 50 drops at 1.5m and 1,000 tumbles at 0.5m — built to survive daily counter use
Flexible mounting
Use countertop, wall-mounted, or integrated into a POS setup — backward compatible with Genesis cables
Depth of field — read range
13 mil UPC (1D)
0 – 250mm
Standard retail barcode
20 mil QR (2D)
0 – 212mm
Mobile screen & printed QR
5.0 mil C39 (1D)
0 – 151mm
High-density linear
10 mil DM (2D)
0 – 129mm
Data Matrix
6.7 mil PDF
0 – 138mm
PDF417 stacked codes
3.0 mil C39 (1D)
0 – 98mm
Ultra high-density
Scan performance
| Scan pattern | Area image, 1280×800 px, 1MP |
| Motion tolerance | 400 cm/s (158 in/s) at optimal focus |
| Scan angle | Horizontal 48° · Vertical 30° |
| Pitch / skew | 65° / 65° |
| Resolution (1D) | 3 mil (0.076mm) |
| Resolution (2D) | 5 mil (0.127mm) |
| Print contrast | 20% minimum reflectance |
Physical & environment
| Dimensions (L×W×H) | 80 × 40 × 105mm (145mm with stand) |
| Weight | 340g |
| IP rating | IP52 |
| Drop resistance | 50 drops @ 1.5m |
| Tumble resistance | 1,000 tumbles @ 0.5m |
| Operating temp | 0°C–50°C |
| Storage temp | -40°C–70°C |
| Humidity | 0%–95% RH (non-condensing) |
| Light level | 100,000 Lux |
Interfaces & electrical
Host interfaces
USB
RS-232
Keyboard Wedge
IBM 46xx (RS-485)
Power
5.0V DC typical
2.5W (500mA @ 5V)
Auxiliary
Pin connector for future expandability
Trigger & feedback
Top-mounted button
360° LED ring
90dB beeper @ 10cm
Ideal for
Retail checkout Cafés & coffee shops Restaurants Takeaway & quick service Hospitality Healthcare & pharmacy
With a 400 cm/s motion tolerance and a 1MP area image sensor, the Voyager 7680G captures barcodes reliably even when customers move items quickly across the scan window — keeping queues moving at peak trading times.
